Wall Sleeve 45° Adjustable – Ø 125 / Black Matt

£ 37,00

Product Details

SKU15-125-100
ItemWall Sleeve 45° Adjustable – Ø 125
Designation:EN1856-1 T600 N1 W V2 L50040 TWPro G50/ KC G60
System:TWPro / KC
Inner Material:316L Stainless Steel – 0.40mm thick
Outer Material:304 Stainless Steel – 0.40mm thick
Fuels:Wood, Oil, Gas, Low sulpher coal
Approvals:HETAS / CE
Distance to Combustibles:TWPro 50mm / KC 60mm

Description

The Adjustable Wall Sleeve is used to protect the chimney in the wall passage when the flue system passes to the outside wall. The gap bewteen the flue and the Wall Sleeve can be filled with rockwool. This Wall Sleeve is precut at 45°, and is adjustable so it can be manually extended within wall.

Description

APPLICATION
For use on solid fuel and gas/oil appliances. eg: woodstoves, gas coal effect fires, oil and gas boiler and any solid fuel appliances.

CONSTRUCTION
Outer skin is made from 304 grade stainless steel and is 0.4mm thick. Inner skin is made from 316 grade stainless steel and is 0.4mm thick. Insulation is compressed rockwool giving a density of 200kg/m3 TWPro / 128Kg/m3. All parts are fully welded.
Distance to combustibles is 50mm TWPro 60mm on KC

APPROVALS
TWPro is HETAS Approved and is CE marked.
Designation Number
TWPro EN1856-1 T600 N1 W V2 L50040 G50.
TWPro EN1856-1 T200 W V2 L50040 O20.
KC EN1856-1 T600 N1 W V2 L50040 G60.
KC EN1856-1 T200 W V2 L50040 O20.

INSTALLATION
TWPro Twin Wall Insulated Chimney parts are secured together by using a Locking Band.
Make sure that you keep the required distance from the outside of the flue to any combustible material (wood, plaster board).

Product Details

SKU15-125-100
ItemWall Sleeve 45° Adjustable – Ø 125
Designation:EN1856-1 T600 N1 W V2 L50040 TWPro G50/ KC G60
System:TWPro / KC
Inner Material:316L Stainless Steel – 0.40mm thick
Outer Material:304 Stainless Steel – 0.40mm thick
Fuels:Wood, Oil, Gas, Low sulpher coal
Approvals:HETAS / CE
Distance to Combustibles:TWPro 50mm / KC 60mm



Product Dimensions
