Tee Cap Ø 125 – Chimney Flue Access Cap for 90/135 Tee
£ 22,00
Inner Material: 316L Stainless Steel – 0.40mm thick
Outer Material: 304 Stainless Steel – 0.40mm thick
Fuels: Wood, Oil, Gas, coal
Approvals: HETAS / UKCA
Distance to Combustibles: 60mm
Warranty: 12 Years
Description
The Tee Cap Ø 125 is an essential component for capping off the bottom or unused end of 90° and 135° tees in your chimney system. It is specifically designed to facilitate easy removal for sweeping and access while maintaining the integrity of your flue system.
- Purposeful Design: Ideal for closing off the bottom or unused end of a 90° or 135° tee, allowing for straightforward access and maintenance of the chimney system.
- High-Quality Construction: Made from 304-grade stainless steel for the outer skin and 316-grade stainless steel for the inner skin, both with a thickness of 0.4mm. This ensures durability and resistance to high temperatures.
- Effective Insulation: Features compressed rock wool insulation with a density of 128kg/m³, which helps maintain a safe distance of 60mm from combustibles.
- Compliance and Safety: HETAS-approved and UKCA-marked, meeting the stringent standards of EN1856-1 T600 N1 W V2 L50040 G60 and EN1856-1 T200 P1 W V2 L50040 O20 for reliability and safety.
- Easy Installation: Secured with a locking band system, ensuring a secure fit and reliable closure of the tee.
Installation Guidelines:
- Maintain Clearance: Ensure the tee cap is installed with a minimum distance of 60mm from any combustible materials, such as wood or plasterboard.
- Secure with Locking Band: Use a locking band to ensure the tee cap is firmly in place and to prevent any gaps or leaks.
