Storm Collar Ø 150 – Ultimate Protection for Chimney Roof Penetrations
£ 41,00
Description
The Storm Collar Ø 150 is an essential component for any chimney system that penetrates through the roof. Designed to ensure watertightness and protect roof flashing from extreme weather conditions, this storm collar is indispensable for maintaining the integrity and longevity of your chimney installation.
- Watertight Seal: Ensures a secure and watertight passage through the roof, preventing water ingress and potential damage.
- Protective Design: Shields the flashing from harsh weather conditions, enhancing its durability and lifespan.
- Easy Installation: This should be installed approximately 25mm above the highest point of the flashing. Once secured, apply a bead of silicone around the top edge and the flue to complete the watertight seal.
- Versatile Application: Suitable for use with solid fuel, gas, and oil appliances, including woodstoves, gas coal-effect fires, and oil boilers.
Construction Details:
- Durable Materials: Features an outer skin made from 304-grade stainless steel and an inner skin of 316-grade stainless steel, both with a thickness of 0.4mm, ensuring robustness and resistance to corrosion.
- Effective Insulation: Packed with compressed rock wool insulation at a density of 128kg/m³, providing excellent thermal protection.
- Fully Welded: All parts are fully welded, ensuring structural integrity and long-term reliability.
- Safety Clearance: Maintains a 60mm distance to combustible materials, adhering to safety standards.
Approvals:
- HETAS-Approved: Certified for use with solid fuel appliances, ensuring compliance with industry safety standards.
- UKCA-Marked: Meets UK and European safety regulations.
- Designation Numbers: EN1856-1 T600 N1 W V2 L50040 G60 for solid fuel installations and EN1856-1 T200 P1 W V2 L50040 O20 for gas/oil appliances.
Installation Guidelines:
- Secure Assembly: KC Twin Wall Insulated Chimney parts are connected using a locking band for a secure fit.
- Maintain Safe Distance: Always ensure a 60mm clearance from the flue’s exterior to any combustible materials such as wood or plasterboard.
