90° Tee Ø 125 – Chimney Flue Connector for Rear Outlet

Description

The 90° Tee Ø 125 is specifically designed for connecting your chimney flue to the rear outlet of solid fuel and gas/oil appliances, including woodstoves, gas coal effect fires, and oil boilers. Its durable construction and high-quality materials ensure a secure and efficient connection for optimal flue gas management.

Key Features:

• Purpose-Built Design: Ideal for applications requiring a 90° bend to connect the flue to the rear outlet of appliances, facilitating a smooth transition in your chimney system.
• Durable Construction: Constructed with an outer skin of 304-grade stainless steel and an inner skin of 316-grade stainless steel, both 0.4mm thick, for enhanced durability and heat resistance.
• Effective Insulation: The tee features compressed rock wool insulation with a density of 128kg/m³, providing reliable thermal protection and maintaining a safe distance of 60mm from combustibles.
• Approval Standards: Compliant with both HETAS and UKCA standards, the 90° Tee Ø 125 is certified under designation EN1856-1 T600 N1 W V2 L50040 G60 and EN1856-1 T200 P1 W V2 L50040 O20, ensuring it meets stringent safety and performance criteria.
• Secure Installation: Utilizes a locking band system to secure the tee within your chimney setup, ensuring a stable and secure connection.

Installation Guidelines:

• Maintain Clearance: Ensure a minimum distance of 60mm from the tee’s exterior to any combustible materials, such as wood and plasterboard, to comply with safety regulations.
• Use Locking Band: Secure the tee using the provided locking band to ensure proper alignment and stability.
